RS 480 ROTADAIRON

Stump grinder for Skid-steer (mini-loader)

This Stump grinder has been designed to grind , trim and crush most species of tree stumps.

Equipped with a unique system to keep a precise control on sweeping speed, to then adapt its work to the type of stump to be treated. The sweeping control is magnetically attached to the carrier for greater comfort.

Trimmer teeth can be repositioned for longer working life !

  • Remote control with magnetic base
  • Sweeping speed control
  • Adjustable trimming teeth

Additional information

Hitch plate

Sweep amplitude

1110 mm (43"5/7)

Weight

160 Kg (352.7 lb)

Carrier: Hydraulic flow

30 to 65 l/min (7.9 to 17.1 US gpm)

Carrier: Pressure

230 bars (3335 psi)

Trimmer rotor diameter with teeth

480 mm (18" 7/8)

Number of teeth

4 pairs (Optional : 8 pairs)

Tooth type

Carbide teeth

Sweep control

Proportional control

Transport dimension (mm)

Rotadairon® RS 480 Stump grinder

Description of the Rotadairon® RS 480 Stump grinder

You’re looking for planing and crushing tree stumps ?  Choose our Rotadairon® RS 480 Stump grinder. This Stump grinder is designed to be paired on mini hydraulic loaders.

This stump grinder allows you to get rid of most species trees stumps. This machine has a sweep amplitude of 1110 mm (43″ 5/7).

Its unique control system allows you to control the sweeping speed and adapt it to the type of stumps to be treated.

Technical Specifications

Size of the machine

  • Sweep amplitude : 1110 mm (43″ 5/7)
  • Length : 2120 mm (39″ 4/5)
  • Height : 1340 mm (27″ 4/7)
  • Total Weight: 160 kg (352.7 lb)

Work Dimension

  • Sweep amplitude : 1110 mm (43″ 5/7)

Equipment

  • Remote control with magnetic base
  • Adjustable trimming teeth
  • Sweeping speed control

Suggestions

The Rotadairon® RS 480 Stump grinder use is for :

  • Tree stumps

Service and Warranty

The Rotadairon® RS 480 Stump grinder is delivered with :

  • a user manual
  • a one-year warranty certificate

It is possible to add a one-year warranty extension (additional option).

Dowload the product sheet
